المزيد من فئات المنتجات

إضاءة LED - مصابيح COB، محركات، وحدات، شرائط

رقم جزء الشركة المصنعة	حالة المخزون	السعر	الكمية	ورقة البيانات	Packaging	Series	ProductStatus	Type	Color	CCT(K)	Wavelength	Configuration	LuminousFlux@Current/Temperature	Current-Test	Temperature-Test	Voltage-Forward(Vf)(Typ)	Lumens/Watt@Current-Test	Current-Max	CRI(ColorRenderingIndex)	ViewingAngle	Features	Size/Dimension	Height	LightEmittingSurface(LES)
LTPL-M08210ZS50-T0 LED COB CCT 5000K 80CRI 16W SMD Lite-On Inc.	3,588	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Discontinued at Mosen	Chip On Board (COB)	White, Cool	5000K 3-Step MacAdam Ellipse	-	Square	1150lm (Typ)	240mA	25°C	36.5V	131 lm/W	400mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08210ZS57-F1 LED COB CCT 5700K 80CRI 16W SMD Lite-On Inc.	3,490	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Obsolete	Chip On Board (COB)	White, Cool	5700K 5-Step MacAdam Ellipse	-	Square	1090lm (Typ)	240mA	25°C	36.5V	124 lm/W	400mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08210ZS57-T0 LED COB CCT 5700K 80CRI 16W SMD Lite-On Inc.	2,313	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Discontinued at Mosen	Chip On Board (COB)	White, Cool	5700K 3-Step MacAdam Ellipse	-	Square	1090lm (Typ)	240mA	25°C	36.5V	124 lm/W	400mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08218ZS27-T0 LED COB CCT 2700K 80CRI 24W SMD Lite-On Inc.	2,805	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Active	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Square	1590lm (Typ)	360mA	25°C	36.5V	121 lm/W	600mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08218ZS30-T0 LED COB CCT 3000K 80CRI 24W SMD Lite-On Inc.	3,086	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	1630lm (Typ)	360mA	25°C	36.5V	124 lm/W	600mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08218ZS40-T0 LED COB CCT 4000K 80CRI 24W SMD Lite-On Inc.	3,014	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Active	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	1650lm (Typ)	360mA	25°C	36.5V	126 lm/W	600mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08218ZS50-F1 LED COB CCT 5000K 80CRI 24W SMD Lite-On Inc.	3,811	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Obsolete	Chip On Board (COB)	White, Cool	5000K 5-Step MacAdam Ellipse	-	Square	1700lm (Typ)	360mA	25°C	36.5V	129 lm/W	600mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08218ZS50-T0 LED COB CCT 5000K 80CRI 24W SMD Lite-On Inc.	2,012	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Discontinued at Mosen	Chip On Board (COB)	White, Cool	5000K 3-Step MacAdam Ellipse	-	Square	1700lm (Typ)	360mA	25°C	36.5V	129 lm/W	600mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08218ZS57-F1 LED COB CCT 5700K 80CRI 24W SMD Lite-On Inc.	2,629	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Obsolete	Chip On Board (COB)	White, Cool	5700K 5-Step MacAdam Ellipse	-	Square	1640lm (Typ)	360mA	25°C	36.5V	125 lm/W	600mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08218ZS57-T0 LED COB CCT 5700K 80CRI 24W SMD Lite-On Inc.	3,109	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Discontinued at Mosen	Chip On Board (COB)	White, Cool	5700K 3-Step MacAdam Ellipse	-	Square	1640lm (Typ)	360mA	25°C	36.5V	125 lm/W	600mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08206ZS27-T0 LED COB CCT 2700K 80CRI SMD Lite-On Inc.	3,035	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Active	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Square	555lm (Typ)	120mA	25°C	36.5V	127 lm/W	200mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08206ZS30-T0 LED COB CCT 3000K 80CRI SMD Lite-On Inc.	3,670	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Active	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	585lm (Typ)	120mA	25°C	36.5V	134 lm/W	200mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08206ZS40-T0 LED COB CCT 4000K 80CRI SMD Lite-On Inc.	3,243	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Active	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	620lm (Typ)	120mA	25°C	36.5V	142 lm/W	200mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08206ZS50-T0 LED COB CCT 5000K 80CRI SMD Lite-On Inc.	3,205	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Discontinued at Mosen	Chip On Board (COB)	White, Cool	5000K 3-Step MacAdam Ellipse	-	Square	637lm (Typ)	120mA	25°C	36.5V	145 lm/W	200mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08206ZS50-F1 LED COB CCT 5000K 80CRI SMD Lite-On Inc.	2,296	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Obsolete	Chip On Board (COB)	White, Cool	5000K 5-Step MacAdam Ellipse	-	Square	637lm (Typ)	120mA	25°C	36.5V	145 lm/W	200mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08206ZS57-T0 LED COB CCT 5700K 80CRI SMD Lite-On Inc.	3,865	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Discontinued at Mosen	Chip On Board (COB)	White, Cool	5700K 3-Step MacAdam Ellipse	-	Square	593lm (Typ)	120mA	25°C	36.5V	135 lm/W	200mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08206ZS57-F1 LED COB CCT 5700K 80CRI SMD Lite-On Inc.	2,438	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Obsolete	Chip On Board (COB)	White, Cool	5700K 5-Step MacAdam Ellipse	-	Square	593lm (Typ)	120mA	25°C	36.5V	135 lm/W	200mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08208ZS27-T0 LED COB CCT 2700K 80CRI SMD Lite-On Inc.	2,596	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Obsolete	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Square	771lm (Typ)	180mA	25°C	36V	119 lm/W	300mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08208ZS27-S1 LED COB CCT 2700K 80CRI SMD Lite-On Inc.	3,664	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Obsolete	Chip On Board (COB)	White, Warm	2700K 5-Step MacAdam Ellipse	-	Square	771lm (Typ)	180mA	25°C	36V	119 lm/W	300mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
LTPL-M08208ZS30-T0 LED COB CCT 3000K 80CRI SMD Lite-On Inc.	2,533	-	RFQ	ورقة البيانات	Tube	LTPL-M08	Obsolete	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	812lm (Typ)	180mA	25°C	36V	125 lm/W	300mA	80	120°	-	13.50mm L x 13.50mm W	1.80mm	9.50mm Dia
